Fiber Laser Marking Machine

Ultra

Power: 20 – 120 Watts
Marking | Engraving | Coding | Traceability | Printing
High Speed Marking & Engraving

Get a Quote
Compact Laser Marking and Engraving Machine - Ultra

Compact Laser Marking and Engraving Machine - Ultra

Laser Marking and Engraving Machine with Enclosure- Front

Laser Marking and Engraving Machine with Enclosure- Front

Laser Marking and Engraving Machine with Enclosure - Right

Laser Marking and Engraving Machine with Enclosure - Right

Laser Marking and Engraving Machine with Enclosure - Left

Laser Marking and Engraving Machine with Enclosure - Left

Laser Marking and Engraving Machine with Enclosure - Back

Laser Marking and Engraving Machine with Enclosure - Back

Laser Marking and Engraving Machine - Ultra

Laser Marking and Engraving Machine - Ultra

Laser Marking and Engraving Machine - Front

Laser Marking and Engraving Machine - Front

Laser Marking and Engraving Machine - Left

Laser Marking and Engraving Machine - Left

Fiber Laser Marking Machine - Right

Fiber Laser Marking Machine - Right

Laser Marking and Engraving Machine - Back

Laser Marking and Engraving Machine - Back

Reasons You'll love Ultra

Permanent Marking
Permanent Marking
Auto Focal Point Adjustment
Auto Focal Point Adjustment
Intuitive Software
Intuitive Software
Coloured Marking
Coloured Marking
Swift Working
Swift Working
Laser Marking and Engraving Machine | Ultra

Laser Marking and Engraving Machine | Ultra

SLTL Group has been producing benchmark Laser Marking systems. With a range of laser marking machines that are differentiated based on the application; SLTL has been working ahead of time. The smart machines are capable of marking all the materials ranging from metals to non-metals. And the marking possibilities are endless, to name a few; applications like marking/ engraving, coloured marking, rotary marking, hallmarking, printing, coding, and traceability. It incredibly imprints over smaller to larger components. Regardless of whether you are a big or a small firm, established or a Start-up, producing small or large-volume components or handling small or large lot sizes – SLTL’s Ultra laser marking systems ensure the best possible ergonomics and safety at all times. Ultra can be efficiently used for marking medical devices which is challenging for medical device manufacturers.

Building a Reliable Technical Experience!

Ever since incorporation, we have been making our own way through futuristic technology and ground-breaking innovations.

  • Overview
  • Features
  • Technical Specification
  • Applications

Product Description

The machines offer high contrast and superficial marking at the highest speed on almost all the components with the ultra-fine designs

Para Matrix & Para Vault

Para Matrix & Para Vault

Intelligent functions of SLTL’s Laser marking machines have an in-built virtual vault created for storing the best laser marking parameters of previously marked materials. Making the marking operations most convenient, the Para matrix helps in determining the best laser marking result on any given material in no time. This feature helps even those who have very less knowledge about laser marking machine operation to mark or engrave effectively.

Fast Focal Position Adjustment

Fast Focal Position Adjustment

While marking different sorts of materials, the focal point of the laser is required to be changed in accordance. The variable beam expansion enables you to move the focal position quickly as per your application requirement, promising high-end marking. Such automation makes Ultra a must-buy for industrial marking requirements.

High-Volume Multi-Piece Part Markings

High-Volume Multi-Piece Part Markings

This smart solution can be integrated with automation like multi-stage indexing, multi-stations or other jigs/fixtures for swift marking operations. The safety-interlocked doors provide fast and efficient parts placement and removal for voluminous marking and enhancing productivity.

Intuitive & High-Performance Software

Intuitive & High-Performance Software

With in-house expertise, SLTL has developed hi-tech software for the most effective marking and engraving applications. One of the key features of the software is its ability to import and store a wide variety of file formats, such as jpeg, png, and vector files allowing operators to easily import existing designs or logos and make them ready for marking. The software also has the ability to create and edit designs, including the ability to add text, graphics, and logos, making it a versatile solution for a variety of industrial applications.

Counterfeit Protection

Counterfeit Protection

The smart laser marking solution Neo’s intuitive software comes with counterfeit protection system to prevent unauthorized duplication or replication of the data. These measures are designed to protect the intellectual property rights of the marking data and to ensure that only authorized users are able to use the software. The best part is that the machine generates unique id and codes directly by the software and marks the same on the desired location.

Unit
Laser Fiber Laser
Laser Power W 20 | 30 | 50 | 60 | 100 |120
Mode of Operation Pulsed
Maximum Peak Power kW >7.5
Operating Temperature Up to 40 °C
Lens F – Theta
Wave Length nm 1060 ±10
Repeatability micron ≤80
Working Area mm 500 x 500
Overall Size (L*B*H) mm 1300 x 850 x 1600
Gross Weight kg 180
Travel (Manual / Motorized) mm 300
Maximum Job Load kg 100
Software Mark-Pro



* Technical specifications are subject to change without prior notice
* 60 & 80 watts power avaiable in special laser source only

Applications

Dynamic marking on Automotive Components

Dynamic marking on Automotive Components

Laser Marking is vital to the Automotive industry for marking big components like the engine, bearings, valves, cylinders and to the small parts like clutch, gears, brakes, piston and even on the delicate parts like mirrors, piston, injector, piston rings. Not only brand name and model number, the laser mark is serialized to give each component its unique identification codes. Marking on the surface of the automotive components for Brand Logo, Digits, Designs, Shapes, & codes.

Unique Identification for Medical equipment

Unique Identification for Medical equipment

Traceability is extremely important element for products in medical industry, which is why machine-readable markings are very important. You can mark implants and surgical instruments in a corrosion-resistant way with the laser marking machines. To improve the tracking or the traceability of instruments used in surgical procedures permanent marking for each instrument with a unique code, digits on needles, blades, scissors, screws, stents can be done.

Ever lasting identification marks for Bearings

Ever lasting identification marks for Bearings

Text, logos, Serial Number on steels, stainless steel, rings, ball bearings, with laser marking is vital for the bearing manufacturers to maintain a competitive edge over brand identity and duplication. Not only brand name and model number, the laser gives a unique identification, essential for all the industries.
