Cutting | Bruiting | Scanning | Coning
SLTL Group has developed and supplied breakthrough technologies covering the entire Diamond industry. One such perfect solution is Hallmark 7G; a blend of advanced innovation with the best practices and a must for all Diamond Manufacturers around the World. It is the Diamond Processing System doing fancy shape cutting like heart, cushion, pear, oval, marquise, princess, cushion, and emerald with the one-time fixing of the stone. This all-in-one machine can perform table sawing, bruiting, and pavilion coning as well as fancy shaping in a single setup.
Ever since incorporation, we have been making our own way through futuristic technology and ground-breaking innovations.
This fully automated machine with intuitive software detects the stone symmetry and crafts exquisite shapes of diamonds in a single setup of diamond rough.
This futuristic Diamond processing system can process different variations of the diamond shape like hearts, cushions, pears, ovals, marquise, princesses, and emeralds. Not just this, the intuitive system can beautifully craft customized shapes and enables the user to maximize productivity and minimize human error when working with more complex fancy shapes.
This power-packed machine can achieve accuracy and run at the fastest speed for processing diamonds in a marginal time without human intervention with a single setup of the stone. A unique sawing method that shapes a rough diamond into its final polished shape in one quick step, this shaping machine add-on is mainly used for fancy shapes.
The Gain is all Yours While processing the diamond stones; SLTL’s futuristic machines provide you with almost zero breakage rates due to Real Time Laser System (RTLS). These machines are built with extremely focused, stable and accurate beam profiles to minimize material wastage and reduce operational errors. SLTL delivers an advanced Processing system which gives you better quality output and satisfying results.
Hallmark 7G has been integrated with super agile software which empowers the machine to work on an extremely low scope of error. So when the Margin of Error is low, productivity exponentially increases and ultimately Cost per Unit decreases.
Software Driving Productivity
With the visual interpretation through the software system, it enhances the adequacy and productivity of the diamond processes giving an advantage over traditional methods. It is a fully automatic system that provides better production without highly skilled manpower. Hallmark 7G has smart intelligence software that detects the stone symmetry and accordingly selects the best cutting parameter for the operation. It delivers an advanced processing system which gives you better quality output and satisfying results.
The perfect blend of an advanced innovation of three-in-one versatility is highly systematic with balance in all 4p, sawing, & shape cutting in a single machine. The different fancy shapes as well as customized Fancy shapes can be created with designs as needed in the rings, earrings, necklaces, bracelets, etc.
| Model | Hallmark-7g |
|---|---|
| Laser Source | SPAQ 75W CW |
| Laser Type | DPSSL |
| Wave Length | 1064 mm |
| Beam Mode | TEM00 |
| Working Power | 4 – 18 Watt |
| CNC Table | 170 × 170 mm |
| Resolution | 1 Micron |
| Repeatability | 3 Micron |
| Accuracy | 2 Micron |
| Drive Type | AC SERVO |
| Z Axis Travel | 100 mm |
| Power Supply | 1 Phase, 15 Amp |
| Power Consumption | 1.7 KW |
| Temperature / Humidity | 20 – 30 °C / <60% |
| Coolant Requirement | 4 – 6 Ltr/Hr |
| Dimension | 1565 × 750 × 1280 mm |
| Computer System | HP, Intel® Core™ i3 |
Cutting
Creating multiple shapes and custom designs is one of the main features of this smart machine which can be intricately created with negligible material loss and is effective for all Jewellery pieces.
Bruiting
SLTL’s technologically advanced laser bruiting machines are equipped with AI, ANN, and IoT to ensure the finest girdle outline and diamond shaping.
Scanning
Hallmark 7G perform Diamond scanning with the smartest 3d scanners for proper mapping of the diamonds to ensure the best cut quality in each gemstone.
Coning
Making those beautiful cone shapes at the bottom of the diamonds is an equally critical task, and the Hallmark 7G is built to create aesthetic shapes in no time.
